How to Use a Woodworking Metal Detector: A Step-by-Step Guide

A woodworking metal detector is only as good as the technique behind it. The best detector in the world will miss embedded metal if you rush the scan, use a weak battery, or skip parts of the board. Here's how to do it right.

Before You Start: The Battery Rule

This is the most important thing to get right, and the most commonly ignored. Always use a fresh, fully charged 9-volt battery.

As a battery drains, detection sensitivity drops — often without any obvious sign that it's happening. You can scan a board with a weak battery, get no alert, and feel confident the lumber is clean. It may not be. A fresh battery is non-negotiable for reliable detection.

For shops that scan frequently, keep spare batteries on hand and replace them on a schedule, not when the detector stops working.

Step 1: Tune the Detector

Lumber Wizard 5: Power on and wait 5 seconds. The Wizard 5 auto-tunes itself — no adjustments needed. Keep it away from large metal objects during tuning.

Little Wizard 2.5: Power on away from metal surfaces. If you hear a continuous beep, use the fine-tuning screw on the top of the unit to stop it. Once the beep stops, the detector is tuned and ready.

Always tune away from your workbench if it's metal, away from large machinery, and away from concrete with rebar underneath.

Step 2: Set Up Your Scan Station

Support the board so you can scan both faces and all edges without awkward repositioning. A pair of sawhorses or a simple outfeed table works well. You want to be able to move the detector smoothly across the full length and width of the board without stopping.

Step 3: Scan the First Face

Hold the detector flat against the wood surface — or as close as possible without touching. Moving too fast reduces sensitivity; aim for a slow, deliberate pace of a few inches per second.

Make overlapping passes across the full width of the board. Don't leave gaps — a missed strip is a missed nail. On the Wizard 5, the 5" scan width covers ground quickly. On the Little Wizard 2.5, make tighter overlapping passes.

Step 4: Flip and Scan the Second Face

Metal embedded closer to the opposite face may not trigger a strong alert from one side. Flip the board and repeat the scan. This takes 30 extra seconds and catches metal that a one-sided scan would miss.

Step 5: Scan the Edges and Ends

Screws and nails near edges are common — especially in old decking, framing lumber, and reclaimed material. Run the detector along both long edges and both ends. The Little Wizard 2.5's angled detection head is especially effective for edge scanning.

Step 6: When the Detector Alerts

Stop moving immediately. Don't sweep past the hit. Hold the detector in place and note the position.

On the Wizard 5, the laser line will project onto the wood surface at the detection point — mark that spot. On the Little Wizard 2.5, watch the LED bar graph and audio alert to find the peak signal, then mark the center.

Extract the metal completely — don't cut around it or leave fragments. Re-scan the area after extraction to confirm it's clean and check for additional metal nearby.

Step 7: Clear to Cut

Once you've scanned all faces and edges, gotten clean passes, and resolved any alerts, the board is cleared for milling. Only then does it go to the planer, jointer, table saw, or router table.

A Quick Reference

1. Fresh battery — always
2. Tune away from metal
3. Slow, overlapping passes
4. Scan both faces
5. Scan edges and ends
6. Stop and mark on every alert
7. Extract completely, re-scan
8. Then cut
